特性阻抗(Ω)Impedance |
50 |
|
|
接触电阻(常 态)( MΩ) Contact resistance |
内导体(MΩ) Inner conductor |
≤0.4 |
|
外导体(MΩ) Outer conductor |
≤0.2 |
|
|
绝缘电阻(常态) (MΩ) Insulation Resistance |
≥1x104 |
|
|
耐压AC(V min) Pressure |
4000V 1min无击穿、无飞弧现象 4000V 1min No breakdown and no arcing phenomenon |
|
|
频率范围(MHz)Frequency Range |
DC～2500 |
|
|
驻 波 比(MHz)V.S.W.R |
≤1.20 |
|
|
插入损耗(dB)Insertion Loss |
≤0.2 |
|
|
额定功率(W)Rated Power |
200 |
|
|
起始放电电压(V) Initial discharge voltage |
230 |
|
|
峰值放电电压(V（1×40μS） Peak discharge voltage |
1000 |
|
|
峰值放电电流(KA) Peak discharge current |
20 |
|
|
重 量(g) Weight |
125 |
|
